Autopilot PX2 Advanced Lighting Controller

Precision photoperiod control for up to 512 fixtures in two independently controlled zones, all from one centralized controller. The PX2 works with any controllable Phantom or Core HID fixtures, as well as PHOTOBIO LED fixtures — each zone can run analog, digital, or one of each.

• Dual-zone control: 512 digital HID fixtures (256 per zone) or 100 analog LED fixtures (50 per zone)
• PPF scheduling: set output by wattage or percentage across the photoperiod
• Sunrise/sunset simulation for a gradual ramp at both ends of the light cycle
• Two temperature sensors (one per zone) with real-time temperature dimming and high-temperature shutdown protection
• Configurable restrike delay to eliminate lamp-damaging hot restrikes
• Built-in battery backup holds your programmed settings through a power outage
• No contactors needed — eliminates inrush current and replaces traditional lighting contactors
• Voltage: 100–240V, 50/60Hz

In the box: PX2 controller, 2 × 50 ft temperature probes, data cables, power adapter, mounting screws, and instructions.
